| Quantity: | |
|---|---|
02A03
HaoRui
02A03
 | High precision Zirconia Ceramic Ring |
A zirconia ceramic ring refers to a circular or annular component made from zirconium dioxide (ZrO2), commonly known as zirconia. Zirconia ceramic rings are valued for their exceptional mechanical and thermal properties, making them suitable for various industrial applications. They can also withstand high temperatures for long periods even under severe mechanical stress. Typical Applications include: volatile chemical solutions transportation, jet and diesel engine components, containers for molten metals, high speed cutting tools, high wear components, transistor insulators, dental implants, bearing balls, pump seals, and ball valves. |
| Zirconia Ceramic Ring Applications: |
| – Seals and Gaskets: Zirconia ceramic rings can be used in applications requiring a durable and reliable seal, such as in mechanical seals for pumps or as part of gaskets in high-temperature environments. – Bearings: Zirconia ceramic rings are often used in high-performance bearings. The material’s hardness, low friction coefficient, and wear resistance make it suitable for applications where traditional metal bearings may fail. |
Zirconia Ceramic （3Y-TZP）Performance Table | |||
| Property | Item | Data | Unit |
| Mechanical Characteristics | Color | Ivory | - |
| Density | 6.02 | g/cm3 | |
| Bending Strength | 800 | MPa | |
| Compressive trength | 3000 | MPa | |
| Elastic Modulus | 200 | GPa | |
| Fracture Toughness | 8 | MPa m1/2 | |
| Weber Coefficient | 15 | m | |
| Vickers Hardness | 1200 | HV 0.5 | |
| Thermal Characterics | Coefficient of Line Thermal Expansion | 10 | 10-6K-1 |
| Thermal Conductivity | 3 | W/mK | |
| Thermal Shock Resistance(Put in Water) | 300 | ΔT °C | |
| Max Working Temperature | 1000 | °C | |
| Electrical Characteristics | Volume Resistance at 20°C | >1013 | Ωcm |
| Dielectric Strength | 11×106 | V/m | |
| Dielectric Constant | 33 | εr | |
| One MHZ Dielectric Loss Angle at 20°C | 0.0016 | tanδ | |
| Chemical Characteristics | Nitric Acid (60%) 90°C | ≒0.00 | WT Loss mg/cm2/day |
| Sulphuric Acid (95%) 95°C | 0.04 | ||
| Caustic Soda (30%) 80°C | 0.08 | ||
The values are typical material properties and may vary according to products configuration and manufacturing process. For more details, Please feel free to contact us.
